JCL17-1 / JCL17-2 LED Marine Pendant Light
- Lamp Body Material: Stainless steel.
- Illuminant: LED.
- Ambient Temperature: -30℃~+55℃.
- Electricity Requirements: AC100～240V 50/60Hz, 2*10W / 2*20W.
- Application: It is suitable for sanitary areas such as kitchens and food stores on ship platforms, as well as laundry rooms and other damp areas.
Tell us your requirements via Enquiry form, Email, WhatsApp
Share to
Specifications of JCL17-1 / JCL17-2 LED Marine Pendant Light
| Type | JCL17-1 | JCL17-2 | ||
| Rated Voltage | AC100～240V 50/60Hz | DC24V | AC100～240V 50/60Hz | DC24V |
| Power | 2×10W | 3W | 2×20W | 3W |
| Power Factor | ≥0.9 | ≥0.9 | ||
| Illuminant | LED | LED | ||
| Illuminant Color | White | White | ||
| Luminous Flux (lm) | 1800lm | 300lm | 3600lm | 300lm |
| Color Rendering Index | Ra≥80 | Ra≥80 | ||
| Color Temperature | 5700K (Optional: 3000K, 4000K, 5000K) | 5700K (Optional: 3000K, 4000K, 5000K) | ||
| Protection Class | IP44 | IP44 | ||
| Cable Outside Diameter | 10mm～14mm | 10mm~14mm | ||
| Installation Method | Ceiling-mounted Type | Ceiling-mounted Type | ||
| Ambient Temperature | -30℃ ~ +55℃ | -30℃ ~ +55℃ | ||
| Lamp Body Material | Stainless steel | Stainless steel | ||
| Lamp Shade Material | Engineering Plastic PC | Engineering Plastic PC | ||
| Lamp Shade color | Transparent | Transparent | ||
| Weight | 4.0kg | 8.0kg | ||
Why Choose Yushuo JCL17-1 / JCL17-2 LED Marine Pendant Light
Yushuo JCL17-1 / JCL17-2 LED marine pendant light It is suitable for all kinds of ships, shipyards, port docks, storage yards and stadiums and other open place lighting.
- High Waterproof Performance: Designed with a sealed structure, it boasts excellent waterproof capabilities with an IP44 rating, making it ideal for use in damp and water-prone environments.
- Compact and Refined Appearance: With a compact structure and refined look, it is both practical and aesthetically pleasing.
- Convenient Installation and Maintenance: Equipped with an imported rotating lamp holder, it facilitates easy internal connections.
- Internal Compensating Capacitance: The light fixture is fitted with compensating capacitance inside, which ensures a good starting effect.
- Compliance with International Standards: It meets the IEC60092-306-2009 standard and the grade entry norms for steel ships, ensuring the product’s quality.
- CCS Certified: Yushuo’s product has been certified by the China Classification Society (CCS), which is a recognition of its quality and safety.
- High Efficiency and Long Lifespan: The LED light source is highly efficient, with a working life that can exceed 50,000 hours.
- Stable Components: The LED starter is composed of stable components, ensuring a long circuit life, and it includes short-circuit and overload protection to ensure the long-term stable operation of the LED light.
- Strong Environmental Adaptability: With a wide working temperature range from -30℃ to +55℃, it is suitable for various climatic conditions.
